Stack Flycolor X-Tower 2 60A F7
Stack Flycolor X-Tower 2 60A F7
Brand: Flycolor
Regular price
€131,89Taxes included.
Regular price
€131,89
Sale price
€131,89
Unit price
/
per
In stock
We have the goods in stock. We usually send the shipment to you within 24 hours of payment. Delivery time usually within two working days.
sku: SKU:X4-FW060006-C2F7-K01
Couldn't load pickup availability
Payment methods
- Description
- Related Files
- Discussion
Stack Flycolor X-Tower 2 60A F7 Function: - High Performance MOSFETs: This assembly features MOSFETs that have low Rds, can handle large currents efficiently, making it ideal for fast flight conditions. - Double-layer tower structure: 4-in-1 ESC and FC are connected by cable in a double-layer tower structure, supported by silicone vibration dampers. This design minimizes the impact of vibration on flight control. - Dimmed Light with Regenerative Braking: The ESC uses Dimmed Light Regenerative Braking technology, which allows very fast engine deceleration and includes active idling. - Universal signal support: The system supports various input pulse widths, including common 1-2ms, Oneshot125, Oneshot42 and Multishot. Additionally, it supports all Dshot and Proshot signals. - Wide receiver compatibility: Compatible with SBUS, SPEKTRUM1024/2048 and other remote control/receive modes. - Integrated power outputs: The flight controller includes integrated 3.3V, 5V and 12V outputs for powering the receiver, VTX, camera, buzzer, LED and other peripherals. - LED port and safe power supply: It has a 4-way LED port with independent 5V BEC power supply, which ensures safer and more reliable power distribution. - Customizable LED colors: LED colors can be adjusted using the Betaflight Configurator. Designed for high performance and versatility, this stack is suitable for demanding flight conditions and supports a wide range of configurations and peripherals. Specifications: Model: X-Tower 2 60A Support voltage: 3-6S Lipo Con. Current: 60A Explosive current: 70A Construction: Tower FC voltage: 3.3V/5V/10V MCU F7: STM32F722 F7 Firmware: STM32F7X2 (Configuration: FLYCOLORF7) ESC firmware: Flycolor_X_Cross_BL_32 Bluetooth: FC_Bluetooth. USB: Type C Installation hole: 30.5×30.5 mm, M3 Size: 41.7×44.8×16.7mm Weight: 26g The package includes: 1x Stack Flycolor X-Tower 2 60A F7
