    Motor iFlight XING2 2306 Unibell 2555KV

    Motor iFlight XING2 2306 Unibell 2555KV

    Brand: iFlight

    €25,65
    €25,65 €25,65
    -0% View Product

    sku: X009345

    Out of stock
    We need to check the product availability with our supplier. Please contact us for details.
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description

    XING2 2306 FPV Motor Unibell 2555KV

    Function:

    - 5mm titanium alloy shaft - Impact resistant 7075 aluminum bell - Long life NSK 9x4x4 smooth bearings - N52H Curved Arc Magnets with Center Groove - Bearing gap protection with XING O-ring - Motor wire protector - Dynamically balanced

    Specifications

    Model: XING2 2306 Engine KV: 2555KV Weight (including wire): 32.5 g Size: ?30*18.7mm Interphase resistance: 50m? Input voltage: 16V Peak current: 51.3A Maximum wattage: 820.8W Mounting holes: 16*16 ?3mm Rotor specifications: Unibell Shaft diameter: 5 mm Length of protruding shaft: 13.5 mm Lead: 160mm/20AWG Magnet: N52H Curved Configuration: 12N14P Bearing type: NSK Bearing specifications: ?9*?4*4 Winding: Single-core copper winding

    The package includes: 1x XING2 2306 brushless motor 4x M3*8 screws 1x M5 flange nut
