    Motor iFlight 1700KV XING-E Pro 2306 2-6S

    Motor iFlight 1700KV XING-E Pro 2306 2-6S

    Brand: iFlight

    €19,78
    €19,78 €19,78
    -0% View Product

    sku: XE10382

    In stock (127)
    We have the goods in stock. We usually send the shipment to you within 24 hours of payment. Delivery time usually within two working days.
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description

    1700KV XING-E Pro 2306 2-6S FPV Motor

    The XING-E Pro series are very powerful and powerful FPV motors for FPV racing. This 2306 size motor features a high strength 4mm steel hollow shaft, single filament winding for increased power, M3 shaft bolt and larger NSK 9x4x4mm bearings.

    Function: - High strength 4mm steel shaft - N52SH High temperature magnets, NSK bearings - Hole pattern 16x16mm - Single-core copper winding - 6061 CNC machined aluminum upper and lower parts - Hexagon screw shaft set screw

    Specifications: Model: XING-E Pro 2306 Motor KV: 1750 KV Weight (including wire): 33.6g / 33.8g Size: ?29*18.7mm Phase-to-phase resistance: 85.63 m? / 55.6 m? Input voltage: 25.2V / 16.8V Peak current: 36.66A / 43.38A Maximum wattage: 920.2W / 712.7W Mounting holes: 16*16 ?3mm Rotor specifications: Unibell Shaft diameter: 4 mm Length of protruding shaft: 13.5 mm Lead: 160mm/20AWG Magnet: N52H Curved Configuration: 12N14P Bearing type: NSK Bearing specifications: ?9*?4*4 Winding: Single-core copper winding

    Packing List: 1 x XING-E Pro 2306 motor 4 x M3*8 screws 1 x M5 flanged nylon lock nut
