    GPS module GEPRC GEP-M10

    GPS module GEPRC GEP-M10

    Brand: GEPRC

    €21,40
    €21,40 €21,40
    -0% View Product

    sku: GP105916

    Out of stock
    We need to check the product availability with our supplier. Please contact us for details.
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description

    The GEPRC GEP-M10 GPS module is a compact and reliable navigation solution for FPV drones, multirotors, fixed-wing aircraft, and other UAV platforms. Equipped with the u-blox M10 GNSS chipset, it provides fast satellite acquisition, stable positioning, and high accuracy across multiple global navigation systems.

    Designed for professional UAV applications, the GEP-M10 supports GPS, BDS, Galileo, QZSS, and SBAS, allowing simultaneous connection to up to 32 satellites for enhanced positioning reliability. Its small form factor and lightweight design make it ideal for space-constrained builds without compromising performance.

    The module includes a built-in Flash chip and farad capacitor, enabling quick hot starts and configuration storage for faster deployment. Its UART interface ensures compatibility with popular flight controllers for straightforward integration.

    Key Features

    • u-blox M10 GNSS chipset for fast and reliable satellite positioning
    • Multi-GNSS support: GPS, BDS, Galileo, QZSS, and SBAS
    • Simultaneous connection to up to 32 satellites for consistent accuracy
    • Compact and lightweight design (22×22×8.2 mm, 7.8 g)
    • Built-in Flash memory and farad capacitor for quick hot starts
    • High sensitivity receiver for stable performance in challenging conditions
    • UART output protocol compatible with most UAV flight controllers

    Specifications.

    • Feature    GEP-M10
    • GPS Chip    u-blox M10
    • Magnetometer    None
    • Barometer    None
    • Input Voltage    3.3V - 5V
    • Supported GNSS    GPS L1, GLONASS L1, BDS B1, Galileo E1, SBAS L1, QZSS L1
    • Channels    72
    • Maximum Satellites    32
    • Output Protocol    UART (ublox)
    • Baud Rate    115,200 bps
    • Output Frequency    10 Hz
    • Speed Accuracy    0.05 m/s
    • Horizontal Position Accuracy    2D ACC 1.5 m (weather)
    • Timing Accuracy    30 ns
    • Receiver Sensitivity    Trace -162 dBm, Capture -160 dBm
    • Max Altitude    50,000 m
    • Max Speed    500 m/s
    • Max Acceleration    4G
    • Dimensions    22×22×8.2 mm
    • Weight    7.8 g
