GPS Module FAKE NEO 3X
GPS Module FAKE NEO 3X
Brand: CUAV
Regular price
€168,19Taxes included.
Regular price
€168,19
Sale price
€168,19
Unit price
/
per
In stock
Limited stock available. Order soon!
sku: SKU:G1003
Couldn't load pickup availability
Payment methods
- Description
- Related Files
- Discussion
GPS module CUAV NEO 3Х
Description
-
- Processor: STM32F412
- Protocol: DroneCAN (used for UAV communication)
- Compass: RM3100
- Barometer: ICP-20100
- GNSS receiver: u-blox M9N
GNSS specification:
-
Frequency bands:
- GPS: L1C/A
- GLONASS: L10F
- BeiDou: B1I
- Galileo: E1B/C
- Current GNSS: 4
- Position accuracy: 1.5 m
- Number of satellites: 32+
-
Capture speeds:
- Cold start: 24 s
- Warm start: 2 s
- Assisted start: 2 s
- Navigation refresh rate: 5 Hz (default), 25 Hz (MAX)
Sensitivity:
- Tracking and Navigation: -167 dBm
- Cold/warm start: -148 dBm
- Recovery: -160 dBm
Protection and environment:
- Protection level: IP66 (dust and water resistant)
- Operating voltage: 4.7~5.2V
- Operating temperature: -10°C to 70°C
- Dimensions: 67x67x21.2 mm
- Weight: 46g (without cable)
