    Frame Partizan Edition PT13

    Frame Partizan Edition PT13

    Brand: Partizan

    €88,33
    €88,33 €88,33
    -0% View Product

    sku: 5944

    Available
    We have the goods available. We usually send the shipment to you within 24 hours of payment. Delivery time usually within two working days.
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description

    Partizan Edition PT-13 frame

    The PT-13 Partizan Edition frame is a highly reliable frameset for heavy duty missions. Its high-strength fuselage design effectively reduces unnecessary shocks and resonances during flight.

    Specifications:
    Model: PT-13 Partizan Edition
    Wheelbase: 575mm
    Arm: 8mm
    Top plate: 2.5mm
    Bottom plate: 5mm 3.5mm
    Dimensions: 507x403x52mm
    FC mounting holes: 30.5mm
    Camera mounting: 19 mm
    Weight: 0.6 kg

    Recommended Parts:
    Flight Control: F405 V4 ICM42688P / F722
    ELECTRONIC CONTROL SYSTEM (ESC): AM32 80A 4v1 ESC
    Motor: 4214-660KV
    Camera: Ratel2 Night Version/ Ratel Pro
    VTX: 4.9-6.2Ghz 3W
    Receiver: ELRS 915Mhz Diversity
    Antenna: RHCP SMA 160mm
    Propeller: 1309-3 blades
    Battery: 6S 30000mah Semi Solid Battery

    Package includes:
    1x Partizan Edition PT-13 frame
    1x set of aluminum post
    1x set of screws
    1x set of nuts
    1x set for printing
    1x PT battery pad
    2x battery strap
