    Antenna Diatone Mamba Ultra 5.8G RHCP 90mm/45mm

    Antenna Diatone Mamba Ultra 5.8G RHCP 90mm/45mm

    Brand: Diatone Mamba System

    €9,68
    €9,68 €9,68
    -0% View Product
    Out of stock
    We need to check the product availability with our supplier. Please contact us for details.

    sku: JH60163-3
    • American Express
    • Apple Pay
    • Google Pay
    • Maestro
    • Mastercard
    • PayPal
    • Shop Pay
    • Union Pay
    • Visa
    View full details
    • Description
    Mamba Ultra 5.8G antenna

Options:
UFL (ipex)/LHCP/Bla/Length: tube 90 mm/ outer wire 45 mm
UFL (ipex)/RHCP/white/length:tube 90mm/outer wire 45mm

Parameters:
Frequency range (MHz): 5500-6000
Polarization: RHCP/LHCP
Gain (dBi): 2.5
VSWR (5800 MHz): < 1.5
Input Connector Type: SMA/AngleMMCX/IPEX(UFL)
Radome material: ABS
Cover color: Bla/White
Operating temperature (°C): -40-60
Rated wind speed (m/s): 60
