AIO FC iFlight BLITZ Whoop F7 V1.1
AIO FC iFlight BLITZ Whoop F7 V1.1
Brand: iFlight
Regular price
€130,44Taxes included.
Regular price
€130,44
Sale price
€130,44
Unit price
/
per
In stock
We have the goods in stock. We usually send the shipment to you within 24 hours of payment. Delivery time usually within two working days.
sku: SKU:B014032
Couldn't load pickup availability
Payment methods
- Description
- Related Files
- Discussion
BLITZ Whoop F7 AIO V1.1 Function: - Separate flight control board to minimize electrical gyro noise; - Through connector DJI O3 and Caddx Vista/Polar Connector; - FC PCB can be disassembled from ESC PCB; - Fix enabled. FC Specifications: MCU: BGA-STM32F745 Gyroscope: ICM42688 Blackbox: 16 MB integrated flash BEC output: 5V 2.5A WS2812 LED strip: Yes Buzzer: Yes Barometer: DPS310 Connector: Micro-USB OSD: IFLIGHT OSD (AT745E) FC firmware: IFLIGHT_BLITZ_F7_AIO Mounting pattern: 25.5*25.5mm φ3mm Dimensions: 35*35mm Weight: 10.5g BEC: 5V 2A / 3A Input voltage: 2-6S, support LIHV battery Smartaudio / IRC Tramp VTX protocol supported ESC Specifications: ESC MCU: BB21 Driver: FD6288 Input voltage: 2-6S Support LIHV battery Output current: 55A, peak value 65A (10 seconds) ESC Firmware: Q-H-40 - Bluejay, 0.16, 24kHz Current sensor: 200 ratio (1/10 mV/A) BEC: NO ESC telemetry: NO Bidirectional DShot: Yes (need to use Bluejay firmware) Supports DShot DShot150/300/600/MultiShot/ OneShot etc. The package includes: 1x BLITZ F7 AIO 2 x capacitor 470uF/35V 1 x XT30U male 18AWG cable 70mm 1 x 1.0-7P cable 50mm-28mm 1 x 1.0-7P cable 50mm 4 x M2 silicone grommets 8x screws M2*12mm 8 x M2 transparent nylon nut 10 x 0.8 mm black Heat shrink tube 10 mm
